DipTrace Schematic – Button-ESP-MCP-V2.0.2022 (PDF)

Output via MCP23017 – для включения светодиодов.

backlog sensor29 8,5,0; sensor29 9,5,0; sensor29 10,5,0; sensor29 11,5,0
backlog sensor29 12,5,0; sensor29 13,5,0; sensor29 14,5,0; sensor29 15,5,0

Input via MCP23017 – Кнопки

backlog sensor29 0,2,1; sensor29 1,2,1; sensor29 2,2,1; sensor29 3,2,1
backlog sensor29 4,2,1; sensor29 5,2,1; sensor29 6,2,1; sensor29 7,2,1

9-я – Кнопка

SwitchMode1 15

Send only MQTT message on switch change. This will stop the switch from controlling power outputs.

tele/tasmota/SENSOR = {“Time”:”2021-01-01T00:00:00″,”Switch1“:”OFF”}
tele/tasmota/SENSOR = {“Time”:”2021-01-01T00:00:00″,”Switch1“:”ON”}

Дополнительные параметры.

backlog SetOption36 0;SetOption65 1;wificonfig 4; SetOption59 1; TelePeriod 150; TimeZone +3

SetOption36 0 – 0 Disable boot loop control
SetOption65 1 – 1 Disable – Device recovery using fast power cycle detection
SetOption59 1 – 1 Enable Send tele/%topic%/STATE in addition to stat/%topic%/RESULT for commands: State, Power and any command causing a light to be turned on.
wificonfig 4 = Retry other AP without rebooting (default)

Display SSD1306

displaymode 0

rule1 on tele-DS18B20#Temperature do publish cmnd/LCDKNOP/DisplayText [s1][l1c1]Dacha: %value% C endon

LEDLink – можно заменить на PWM и управлять подсветкой кнопок.
